Twin Eagle Gyro Kit $23,500.
Twin Eagle Specifications 1-2-2020
Engine; Subaru EJ-22, 130HP @ 5200 RPM, Multi-Point Fuel Injected, Electric start. Other engines available at additional cost.
Reduction Drive: 1.88:1, Gates Poly Chain, Prop 2660 @ 5200 RPM
Rotor Blades: Dragon Wings 28' X 7" chord
Special Features: Front control stick activated electric hydraulic pump for the pre-rotator & electric pitch trim. Electric rotor brake, dual controls, adjustable front seat, rear control stick.
Prop: Warp Drive 68" 4 blade ground adjustable, Rotax bolt pattern, Static thrust- 550 LBS @ 5,000 RPM; prop rpm- 2,660.
Length: 14' 8" (176"); Width-5'3" (63"); Height- 9'1" (109").
Gross Weight: 1210 LBS. Empty weight 675 LBS. Fuel- 75 LBS; Usefull load 460 LBS. Front pilot weight- 230 LBS. Rear passenger weight- 230 LBS.
Other Specs
Climb: 800 FPM single; 600 FPM dual. Minimum 35 MPH, Cruise 60 MPH; Top speed 90+; Never exceed speed 120 MPH. Fuel 16 Gal, Burn 4.5 GPH. Gauges: Altimeter, Air speed, Compass, Tachometer, Oil pressure, Water temp, Voltmeter, Hour meter, Main wheel brakes, Tall Tail, seat belts. Average assembly time 120 hours. Colors: Artic White or Midnight Black.
